15mm/s Rubber Vacuum Vulcanizing Press Automatic 140020001600MM

Name: 15mms Rubber Vacuum Vulcanizing Press Automatic 140020001600MM
Brand: Fulund
Price: 1 USD

Wholesale 15mm/s Rubber Vacuum Vulcanizing Press Automatic 1400*2000*1600MM from china suppliers

Brand Name : Fulund

Model Number : FLD-B09-1

Certification : CE

Place of Origin : CHINA

MOQ : 1

Price : competitive

Payment Terms : T/T, Western Union, MoneyGram

Supply Ability : 100PCS/MONTH

Delivery Time : 7days

Packaging Details : WOODEN CASE

NAME : Flat vulcanizing machine

Automatic grade : Semi-Automatic, Automatic, manual

Core Components : PLC

Dimension(L*W*H) : 1400*2000*1600MM

Voltage : AC380V±5%

Power (kW) : 12

Keyword 1 : rubber vulcanizing press

Keyword 2 : press machine

Keyword 3 : rubber machine

Contact Now

Rubber Vacuum Vulcanizing Press

Fulund has a long history since its establishment in 1999. Due to the needs of development, the original brand (TYL) expanded the new brand Fulund in 2022 . Fulund has customers all over the world,such as international brands shoe manufacturer.

1.Main uses:

The Curing Press mainly works for the clampdown of rubber, which can be used as normal hydraulic machine.

We have both column and frame structure.

2.Advantages:

1. Simple and convenient structure, flexible operation,commodious space. The cylinder and plunger are made up of high–quality materials.

2. Hydraulic station and electric cabinet are Located in both sides of the main engine.

3. Conveniently operated.

4. Without oil spilling or off pressure.

5. Excellent reputation.

Model	30T	40T	50(63)T
Temperature regulation	At room temperature ~ 300	At room temperature ~ 300	At room temperature ~ 300
normal temperature-200 degrees heating speed	about15min	about15min	about15min
Temperature precision	automatic/±2°C	automatic/±2°C	automatic/±2°C
Machine operation	control Circuit	control Circuit	PLC touch-screen
Drive way	hydraulic	hydraulic	hydraulic
pressure	10-20Mpa	10-20Mpa	10-20Mpa
power supply	AC380V ± 5%50/60Hz	AC380V ± 5%50/60Hz	AC380V ± 5%50/60Hz
Power:	12KW	15KW	18KW
Motor Power	4KW	4KW	5.5KW
Heating plate distance	200MM	200MM	200MM
Oil cylinder stroke	200MM	200MM	200MM
Movement mode of skateboard	Automatic	Automatic	Automatic
Speed of rise and fall	≥15mm/s	≥15mm/s	≥25mm/s
Pressure regulation mode	Pressure relay	Pressure relay	Digital modulation
Hot pressing time	0.1s to 999s	0.1s to 999s	0.1s to 999s
Maximum pressure	300KN	400KN	500(630)KN
Sliding plate area	440 * 500MM	440 * 500MM	460 * 550MM
Heating plate area	400 × 400MM	400 * 400MM	400 * 450MM
host volume	1400 × 2000 × 1600MM	1400 × 2000 × 1700MM	1500 × 2000 × 1800MM
weight	1200KG	1350KG	1500KG

15mm/s Rubber Vacuum Vulcanizing Press Automatic 1400*2000*1600MM
